| TC-V |
Torque Converter Pressure Valve |
LP-V |
Line Pressure Valve |
| TCC-V |
Torque Converter Clutch Valve |
Park-V |
Park Pawl Release Valve |
| TCHx-V |
Torque Converter Holding Valve |
Park-Cyl |
Park Pawl Release Cylinder |
| PR-V |
Priming Valve |
Red-V |
Pressure Reducing Valve |
| SOLx |
Solenoid |
Pos-V |
Position Valve |
| LPR-V |
Lubrication Pressure Relief Valve |
PosD-V |
Default Position Valve (Driving Default Mode) |
| SV-TC |
Switching Valve-Torque Converter |
CV-x |
Clutch Apply Valve |
| RET-V |
Line Pressure Retention Valve |
HV-x |
Holding Valve |
| RB-V |
Rocker Ball Valve |
|
|
