Module-Transmission Control (DF7 6 Speed) Connector End View (D3855A)

Harness-Family: Dash

Color: BLACK

Gender: FEMALE

Part Number: 7158-7475-30_7283-9412-30

Part Description: Not Available

Connector No: D3855A

Option: DF7 6 SPEED

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Transmission Control Connector End View (DF7 6 SPEED)

Courtesy of CHRYSLER

Fig 2: Module-Transmission Control Component Location (DF7 6 SPEED)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A192

VT/RD

0.75

FUSED B(+)

N/A

D30

0.75

CAN C (-)

N/A

D29

VT/WH

0.75

CAN C (+)

N/A

Z907

0.75

GROUND

N/A

F942

PK/VT

0.50

FUSED IGNITION RUN

N/A

⁽¹⁾	Pins not listed are not used for this connector
