Module-Trailer Tow C1 (Standard) Connector End View (D2399A)

Harness-Family: Body

Color: GRAY

Gender: FEMALE

Part Number: 33472-1207

Part Description: Not Available

Connector No: D2399A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Trailer Tow C1 Connector End View (Standard)
GCWD1014116Courtesy of CHRYSLER
Fig 2: Module-Trailer Tow C1 Component Location (Standard)
GCWD1257234Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 A991 RD 0.75 FUSED B(+) N/A
2 A992 RD 0.75 FUSED B(+) N/A
3 F944 PK/GN 0.50 FUSED IGNITION N/A
5 Z943 BK 0.75 GROUND N/A
7 D191 BN/OG 0.50 CAN IHS (+) N/A
8 D192 WH/OG 0.50 CAN IHS (-) N/A
9 L62 WH/YE 1.0 RIGHT REAR TURN LAMP DRIVER N/A
10 L63 WH/DG 1.0 LEFT REAR TURN LAMP DRIVER N/A
11 L54 WH/GN 0.75 RIGHT STOP LAMP DRIVER N/A
(1) Pins not listed are not used for this connector
