Module-Heated Seats C4 (Standard) Connector End View (D3846D)

Harness-Family: Seat_Pass

Color: BLUE

Gender: FEMALE

Part Number: 9-1355493-3

Part Description: Not Available

Connector No: D3846D

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Heated Seats C4 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Heated Seats C4 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

F945

PK/GN

0.75

FUSED IGNITION

N/A

⁽¹⁾	Pins not listed are not used for this connector
