Module-EPS C2 (Standard) Connector End View (D2777B)

Harness-Family: Dash

Color: BLUE

Gender: FEMALE

Part Number: 4540312/20

Part Description: Not Available

Connector No: D2777B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Eps C2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Eps C2 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A951

8.0

FUSED B(+)

N/A

Z911

8.0

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
