Module-Body Control C4 (Standard) Connector End View (D2762D)

Harness-Family: Dash

Color: BLACK

Gender: FEMALE

Part Number: 15482409_15482404

Part Description: Not Available

Connector No: D2762D

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Body Control C4 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Body Control C4 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

G70

VT/BU

0.50

HOOD AJAR SWITCH SENSE

N/A

Q552

OG/DB

0.50

SUNROOF ENABLE/DISABLE

N/A

B134

DG/YE

0.35

BRAKE SIGNAL 2

N/A

L58

WH/YE

0.75

LEFT DRL LAMP DRIVER

N/A

F944

PK/GN

0.35

FUSED IGNITION

N/A

F944

PK/GN

0.35

FUSED IGNITION

N/A

B20

DG/OG

0.50

BRAKE FLUID LEVEL SIGNAL

N/A

BN/BG

0.35

WASHER SWITCH SENSE

N/A

B135

DG/GN

0.35

BRAKE SIGNAL 1

N/A

DG/WH

0.75

HORN RELAY CONTROL

N/A

BN/VT

0.75

ELECTRIC WINDSHIELD WIPER DE-ICER CONTROL

N/A

L59

WH/DB

0.75

RIGHT DRL LAMP DRIVER

N/A

F941

PK/WH

0.35

IGNITION RUN/START CONTROL OUTPUT

N/A

F941

PK/WH

0.50

IGNITION RUN/START CONTROL OUTPUT

N/A

D52

WH/BU

0.50

CAN CH (+)

N/A

D51

WH/BN

0.50

CAN CH (-)

N/A

BN/GY

0.50

WIPER PARK SWITCH SENSE

N/A

W11

BN/VT

0.50

LOW WASH SW RTN 1

N/A

K57

BN/WH

0.75

FUEL HEATER RELAY CONTROL

DIESEL

L150

BG/GY

0.50

LED CONTROL SIGNAL 2

PREMIUM LIGHTING EXCEPT DIESEL

P330

GN/DG

0.50

LUMBAR RELAY CONTROL

N/A

P501

GN/GY

0.50

DRIVER MIRROR TURN SIGNAL DRIVER

N/A

L61

WH/GN

0.50

LEFT FRONT TURN LAMP DRIVER

N/A

D401

0.35

LIN BUS 1

N/A

C115

0.35

DEFOGGER RELAY CONTROL

N/A

P502

GN/DG

0.50

PASSENGER MIRROR TURN SIGNAL DRIVER

N/A

E12

OG/GY

0.50

PANEL LAMPS DRIVER

N/A

L60

WH/BG

0.50

RIGHT FRONT TURN LAMP DRIVER

N/A

F100

PK/VT

0.50

FUSED IGNITION RUN CONTROL OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
