Can Bus Splice Block 9 (Standard) Connector End View (D3205A)

Harness-Family: Dash

Color: PURPLE

Gender: FEMALE

Part Number: 33178007_33177196_13678636

Part Description: Not Available

Connector No: D3205A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Can Bus Splice Block 9 Connector End View (Standard)
GCWD1013093Courtesy of CHRYSLER
Fig 2: Can Bus Splice Block 9 Component Location (Standard)
GCWD1257524Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 D1 BG/WH 0.75 CAN C (+) N/A
2 D1 BG/WH 0.75 CAN C (+) N/A
3 D29 VT/WH 0.75 CAN C (+) N/A
5 D37 BN/YE 0.75 CAN C (+) N/A
7 D2 YE 0.75 CAN C (-) N/A
8 D2 YE 0.75 CAN C (-) N/A
9 D30 YE 0.75 CAN C (-) N/A
11 D38 YE 0.75 CAN C (-) N/A
(1) Pins not listed are not used for this connector
