Can Bus Splice Block 8 (Standard) Connector End View (D3204A)

Harness-Family: Front_End_Module

Color: PURPLE

Gender: FEMALE

Part Number: 33178007_33177196_13678636

Part Description: Not Available

Connector No: D3204A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Can Bus Splice Block 8 Connector End View (Standard)
GCWD1013093Courtesy of CHRYSLER
Fig 2: Can Bus Splice Block 8 Component Location (Standard)
GCWD1256828Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 D1 BG/WH 0.75 CAN C (+) N/A
2 D1 BG/WH 0.75 CAN C (+) N/A
3 D249 YE/GY 0.75 CAN C (+) N/A
7 D2 YE 0.75 CAN C (-) N/A
8 D2 YE 0.75 CAN C (-) N/A
9 D248 YE 0.75 CAN C (-) N/A
(1) Pins not listed are not used for this connector
