Can Bus Splice Block 2 (Standard) Connector End View (D3198A)

Harness-Family: IP

Color: RED

Gender: FEMALE

Part Number: 33190053_33157038

Part Description: Not Available

Connector No: D3198A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Can Bus Splice Block 2 Connector End View (Standard)
GCWD1000283Courtesy of CHRYSLER
Fig 2: Can Bus Splice Block 2 Component Location (Standard)
GCWD1256889Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 D181 VT/WH 0.50 CAN IHS (+) N/A
2 D17 OG 0.50 CAN IHS (+) N/A
3 D463 OG 0.50 CAN IHS (+) N/A
5 D101 DG 0.50 CAN IHS (+) N/A
6 D182 WH 0.50 CAN IHS (-) N/A
7 D18 WH/OG 0.50 CAN IHS (-) N/A
8 D462 WH 0.50 CAN IHS (-) N/A
10 D102 WH 0.50 CAN IHS (-) N/A
(1) Pins not listed are not used for this connector
