Can Bus Splice Block 16 (Standard) Connector End View (D3212A)

Harness-Family: IP

Color: BLUE

Gender: FEMALE

Part Number: 33190054_33157038

Part Description: Not Available

Connector No: D3212A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Can Bus Splice Block 16 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Can Bus Splice Block 16 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

0.50

CAN CH (+)

N/A

0.50

CAN CH (+)

N/A

D253

YE/DG

0.50

CAN CH (+)

N/A

0.50

CAN CH (-)

N/A

0.50

CAN CH (-)

N/A

D252

0.50

CAN CH (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
