Can Bus Splice Block 10 (Standard) Connector End View (D3206A)

Harness-Family: Dash

Color: PURPLE

Gender: FEMALE

Part Number: 33190055_33157038

Part Description: Not Available

Connector No: D3206A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Can Bus Splice Block 10 Connector End View (Standard)
GCWD1000182Courtesy of CHRYSLER
Fig 2: Can Bus Splice Block 10 Component Location (Standard)
GCWD1257511Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 D1 BG/WH 0.75 CAN C (+) N/A
2 D1 BG/WH 0.50 CAN C (+) N/A
3 D301 WH 0.50 CAN C (+) N/A
5 D429 GY 0.50 CAN C (+) N/A
6 D2 YE 0.75 CAN C (-) N/A
8 D302 DG 0.50 CAN C (-) N/A
10 D430 YE 0.50 CAN C (-) N/A
(1) Pins not listed are not used for this connector
