Can Bus Splice Block (Standard) Connector End View (D331A)

Harness-Family: Jumper_NOX_Particulate_Matter

Color: BLACK

Gender: FEMALE

Part Number: 13678638_33177196_13678636

Part Description: Not Available

Connector No: D331A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Can Bus Splice Block Connector End View (Standard)
GCWD1255745Courtesy of CHRYSLER
Fig 2: Can Bus Splice Block Component Location (Standard)
GCWD1256845Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 D469 GY 0.75 PRIVATE CAN (+) N/A
2 D469 GY 0.75 PRIVATE CAN (+) N/A
3 D484 GY/DG 0.75 PRIVATE CAN (+) N/A
4 D482 GY/VT 0.75 PRIVATE CAN (+) N/A
7 D468 GY/WH 0.75 PRIVATE CAN (-) N/A
8 D468 GY/WH 0.75 PRIVATE CAN (-) N/A
9 D485 BG 0.75 PRIVATE CAN (-) N/A
10 D483 BG 0.75 PRIVATE CAN (-) N/A
(1) Pins not listed are not used for this connector
