Assembly-Power Distribution Center-Rear C1 (Standard) Connector End View (D6631A)

Harness-Family: Body

Color: GRAY

Gender: FEMALE

Part Number: 0301564_0301566

Part Description: Not Available

Connector No: D6631A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Assembly-Power Distribution Center-Rear C1 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Assembly-Power Distribution Center-Rear C1 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

GN/OG

2.0

SEAT SWITCH B(+) SUPPLY

N/A

P103

GN/PK

0.50

DRIVER LUMBAR MOTOR DRIVER

N/A

F945

PK/GN

0.75

FUSED IGNITION

N/A

F943

PK/GN

1.5

FUSED IGNITION

N/A

P690

RD/GN

2.5

FUSED IGNITION RUN CONTROL OUTPUT

N/A

P690

RD/GN

2.5

FUSED IGNITION RUN CONTROL OUTPUT

N/A

F946

PK/GN

2.5

FUSED IGNITION RUN/START CONTROL OUTPUT

N/A

F946

PK/GN

2.5

FUSED IGNITION RUN/START CONTROL OUTPUT

N/A

A906

RD/GY

2.5

FUSED B(+)

N/A

A906

RD/GY

2.5

FUSED B(+)

N/A

A906

RD/GY

2.5

FUSED B(+)

N/A

A906

RD/GY

2.5

FUSED B(+)

N/A

A401

RD/GN

2.0

FUSED B(+)

N/A

A942

2.0

FUSED B(+)

N/A

A130

VT/RD

4.0

FUSED B(+)

N/A

A720

VT/RD

2.0

FUSED B(+)

N/A

Z943

0.50

GROUND

N/A

P330

GN/DG

0.50

LUMBAR RELAY CONTROL

N/A

P690

RD/GN

2.5

FUSED IGNITION RUN CONTROL OUTPUT

N/A

A906

RD/GY

4.0

FUSED B(+)

N/A

Z943

0.50

GROUND

N/A

P330

GN/DG

0.50

LUMBAR RELAY CONTROL

N/A

Z943

0.50

GROUND

N/A

F948

PK/GN

0.35

FUSED IGNITION

N/A

GN/RD

2.5

FUSED B(+)

N/A

F946

PK/GN

2.5

FUSED IGNITION RUN/START CONTROL OUTPUT

N/A

A720

VT/RD

2.0

FUSED B(+)

N/A

A906

RD/GY

4.0

FUSED B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
