Module-Powertrain Control C2 (2.4L) Connector End View (D3821B)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 2098489-1_2098866-1

Part Description: Not Available

Connector No: D3821B

Option: 2.4L

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Powertrain Control C2 Connector End View (2.4L)
GCWD1240031Courtesy of CHRYSLER
Fig 2: Module-Powertrain Control C2 Component Location (2.4L)
GCWD1257470Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 N35 VT 1.0 VVA SOLENOID 2 RETURN N/A
2 N36 DB/PK 1.0 VVA SOLENOID 3 SIGNAL N/A
3 N37 DB 1.0 VVA SOLENOID 3 RETURN N/A
4 N38 DG/PK 1.0 VVA SOLENOID 4 SIGNAL N/A
5 N39 DG 1.0 VVA SOLENOID 4 RETURN N/A
10 K2 VT/OG 0.35 ECT SIGNAL N/A
11 K1 VT/BN 0.50 MAP SIGNAL N/A
16 K42 DB/YE 0.50 KS 1 SIGNAL N/A
17 G6 VT/GY 0.50 EOP SIGNAL N/A
18 K904 DB/DG 0.50 O2 RETURN (DOWNSTREAM) N/A
20 K41 DB/BU 0.50 O2 1/1 SIGNAL N/A
21 K902 BN/DG 0.50 O2 RETURN (UPSTREAM) N/A
24 K447 BG/YE 0.75 ETC MOTOR (+) N/A
25 N34 VT/PK 1.0 VVA SOLENOID 2 SIGNAL N/A
26 N33 BN 1.0 VVA SOLENOID 1 RETURN N/A
27 N32 BN/PK 1.0 VVA SOLENOID 1 SIGNAL N/A
32 A804 RD/VT 0.50 GEN SENSE N/A
33 G24 VT/BN 0.50 EOT SIGNAL N/A
34 K915 BN/WH 0.50 SENSOR GROUND N/A
40 K942 BN/GN 0.50 KS 1 RETURN N/A
41 K103 BN/BU 0.50 O2 1/1 PUMP CELL CURRENT TRIM N/A
42 K141 DB/YE 0.50 O2 1/2 SIGNAL N/A
44 K89 BN/GN 0.50 O2 1/1 POSITIVE CURRENT CONTROL N/A
45 F856 YE/PK 0.50 5 VOLT SUPPLY N/A
46 F855 PK/YE 0.75 5 VOLT SUPPLY N/A
48 K448 BG/OG 0.75 ETC MOTOR (-) N/A
49 K17 DB/BG 1.0 COIL CONTROL 2 N/A
50 K19 DB/DG 1.0 COIL CONTROL 1 N/A
56 K21 DB/GN 0.75 IAT SIGNAL N/A
63 K441 DB/BN 0.50 CMP SENSOR SIGNAL N/A
64 K925 DB/GY 0.50 CKP GROUND N/A
66 K900 BK/PK 0.50 SENSOR GROUND N/A
68 K22 BN/OG 0.50 TP 1 SIGNAL N/A
69 K122 BN/DG 0.50 TP 2 SIGNAL N/A
70 K922 BN/DB 0.50 TP SENSOR RETURN N/A
73 K18 DB/OG 1.0 COIL CONTROL 3 N/A
74 K15 DB/GY 1.0 COIL CONTROL 4 N/A
76 K79 BN/BU 1.0 O2 1/1 HEATER CONTROL N/A
77 K299 BN/WH 1.0 O2 1/2 HEATER CONTROL N/A
82 K11 BN/YE 0.75 INJECTOR CONTROL 1 N/A
83 K12 BN/DB 0.75 INJECTOR CONTROL 2 N/A
84 K13 BN/BU 0.75 INJECTOR CONTROL 3 N/A
85 K14 BN/BG 0.75 INJECTOR CONTROL 4 N/A
88 K24 BN/BU 0.75 CKP SIGNAL N/A
96 K20 BN/GY 1.0 GEN FIELD CONTROL N/A
(1) Pins not listed are not used for this connector
