Module-Drive Train Control C1 (Standard) Connector End View (D3872A)

Harness-Family: Dash

Color: BLACK

Gender: FEMALE

Part Number: 284743-1_5-284871-3

Part Description: Not Available

Connector No: D3872A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Drive Train Control C1 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Drive Train Control C1 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T338

DG/BG

2.5

RDM MOTOR (+)

N/A

T339

DG/GN

2.5

RDM MOTOR (-)

N/A

T323

2.5

PTU MOTOR (+)

N/A

T324

DG/GY

2.5

PTU MOTOR (-)

N/A

A194

RD/GY

2.5

FUSED B(+)

N/A

Z913

2.5

GROUND

N/A

S001

0.75

SHIELD 1

N/A

T335

DG/YE

0.35

RDM POSITION SENSOR RETURN

N/A

T304

YE/BK

0.50

PTU POSITION SENSOR RETURN

N/A

D301

0.50

CAN C (+)

N/A

S003

0.75

SHIELD 3

N/A

T330

DG/BN

0.35

RDM TEMP SENSOR RETURN

N/A

T320

YE/VT

0.50

PTU TEMP SENSOR RETURN

N/A

F949

PK/GN

0.75

FUSED IGNITION

N/A

T303

YE/PK

0.50

PTU POSITION SENSOR SUPPLY

N/A

T334

DG/GY

0.35

RDM POSITION SENSOR 2 SIGNAL

N/A

T322

DG/BK

0.50

PTU POSITION SENSOR 2 SIGNAL

N/A

D302

0.50

CAN C (-)

N/A

A198

RD/OG

0.75

FUSED B(+)

N/A

T332

DG/VT

0.35

RDM POSITION SENSOR SUPPLY

N/A

T331

DG/OG

0.35

RDM TEMP SENSOR SIGNAL

N/A

T319

0.50

PTU TEMP SENSOR SIGNAL

N/A

T333

DG/WH

0.35

RDM POSITION SENSOR 1 SIGNAL

N/A

T321

DG/WH

0.50

PTU POSITION SENSOR 1 SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
