Sensor-Front Impact-Left (Standard) Connector End View (D3164A)

Harness-Family: Dash

Color: NATURAL

Gender: FEMALE

Part Number: 1-1924067-5

Part Description: Not Available

Connector No: D3164A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Sensor-Front Impact-Left Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Sensor-Front Impact-Left Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R79

BU/VT

0.50

LEFT FRONT IMPACT SENSOR SIGNAL

N/A

R81

BU/WH

0.50

LEFT FRONT IMPACT SENSOR GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
