Module-Powertrain Control C2 (Standard) Connector End View (D3837B)

Harness-Family: Engine_Diesel

Color: BLACK

Gender: FEMALE

Part Number: 1/11902/07

Part Description: Not Available

Connector No: D3837B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Powertrain Control C2 Connector End View (Standard)
GCWD1012981Courtesy of CHRYSLER
Fig 2: Module-Powertrain Control C2 Component Location (Standard)
GCWD1240087Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 K682 YE/RD 0.75 EGR CONTROL 1 1.6L DIESEL
2 K684 YE/VT 0.75 EGR CONTROL 2 1.6L DIESEL
3 K635 GY/RD 0.75 TURBOCHARGER ACTUATOR (+) 1.6L DIESEL
5 N117 GY/BN 0.50 INTAKE SWIRL SERVO MOTOR CONTROL N/A
6 K366 OG/BK 0.75 FUEL QUANTITY SOLENOID 12 VOLT SUPPLY N/A
7 K365 YE/BK 0.75 FUEL QUANTITY CONTROL N/A
8 K314 YE/RD 0.75 TTVA MOTOR (+) N/A
9 K315 BK/GN 0.75 TTVA MOTOR (-) N/A
12 K385 GN/YE 0.50 EXHAUST GAS TEMP 2 PRE N/A
13 K384 GN/WH 0.50 EXHAUST TEMPERATURE SENSOR 4 SIGNAL N/A
16 K313 RD 0.50 EGR AIR FLOW CONTROL POSITION SUPPLY N/A
17 K834 WH/DB 0.50 5 VOLT SUPPLY 1.6L DIESEL
20 K24 GY/BK 0.75 CKP SIGNAL N/A
21 K925 WH/YE 0.75 CKP GROUND N/A
22 K12 BN/WH 1.5 INJECTOR CONTROL 2 1.6L DIESEL
24 K13 OG/DB 1.4 INJECTOR CONTROL 3 1.6L DIESEL
25 K639 GY/BK 0.75 BOOST PRESSURE SERVO RETURN 1.6L DIESEL
28 K945 GY/BN 0.75 ACTUATOR SWIRL END POSITION RTN N/A
29 K351 GN/BK 0.50 5V ACTUATOR SWIRL END POSITION N/A
30 G60 GY 0.50 OIL PRESS SENSE/SW SIG 2 N/A
35 K666 BK/RD 0.50 SENSOR RETURN 1.6L DIESEL
36 K691 BN 0.50 EGR COOLER TEMP SIGNAL 1.6L DIESEL
37 K844 RD/BK 0.50 CMP 5 VOLT SUPPLY 1.6L DIESEL
38 K668 WH/OG 0.50 5 VOLT SUPPLY N/A
39 K551 RD/YE 0.50 5 VOLT SUPPLY 1.6L DIESEL
40 K685 DB/WH 0.50 EGR POSITION SENSOR SIGNAL 2 1.6L DIESEL
40 K834 DB/WH 0.50 5 VOLT SUPPLY 2.0L DIESEL
42 K350 RD/GN 0.50 FUEL PRESSURE 5 VOLT SUPPLY N/A
43 K612 BN/BK 1.5 INJECTOR 2 CONTROL 1.6L DIESEL
45 K613 OG/GN 1.5 INJECTOR 3 CONTROL 1.6L DIESEL
46 K79 RD/VT 0.75 O2 1/1 HEATER CONTROL N/A
50 G6 GY/DB 0.50 EOP SIGNAL N/A
51 K944 VT/WH 0.50 CMP GROUND 1.6L DIESEL
52 K44 GY 0.50 CMP SENSOR SIGNAL 1/1 1.6L DIESEL
55 K900 GY/YE 0.50 SENSOR GROUND N/A
56 K185 GN 0.50 EXHAUST TEMPERATURE SENSOR 1 SIGNAL N/A
57 K934 WH/GN 0.50 EGR SENSOR GROUND 1.6L DIESEL
58 K683 GN 0.50 EGR SIGNAL 1.6L DIESEL
61 K48 WH/GN 0.50 AIR TEMP SENSOR SIGNAL N/A
62 K181 YE 0.50 FUEL PRESSURE SIGNAL N/A
63 K359 BK/VT 0.50 FUEL PRESSURE SENSOR GROUND N/A
64 K11 WH/RD 1.5 INJECTOR CONTROL 1 1.6L DIESEL
66 K14 OG/WH 1.5 INJECTOR CONTROL 4 1.6L DIESEL
67 K677 GY/RD 0.75 HP EGR VALVE ACTUATOR (+) 1.6L DIESEL
67 K682 GY/RD 0.75 EGR CONTROL 1 2.0L LITE
69 K670 WH/VT 0.75 EGR BYPASS VALVE SIGNAL N/A
74 K900 OG 0.50 SENSOR GROUND 1.6L DIESEL
75 K372 YE 0.50 EXHAUST TEMPERATURE 1/3 SENSOR SIGNAL 1.6L DIESEL
76 K552 GN/BK 0.50 SENSOR GROUND 1.6L DIESEL
77 K553 GY/WH 0.50 TURBO POSITION SIGNAL N/A
78 K934 VT/RD 0.50 EGR SENSOR GROUND N/A
79 K682 DB 0.50 EGR CONTROL 1 1.6L DIESEL
79 K683 DB 0.50 EGR SIGNAL 2.0L LITE
83 K902 RD/BK 0.50 O2 RETURN (UPSTREAM) N/A
84 K41 RD/YE 0.50 O2 1/1 SIGNAL N/A
85 K611 DB 1.5 INJECTOR 1 CONTROL 1.6L DIESEL
87 K614 OG/BK 1.5 INJECTOR 4 CONTROL 1.6L DIESEL
88 K678 DB/BK 0.75 SENSOR RETURN 1.6L DIESEL
88 K684 DB/BK 0.75 EGR CONTROL 2 2.0L LITE
90 G62 DB/BK 0.75 OIL PRESSURE SOL CONTROL 1.6L DIESEL
95 K690 BN/VT 0.50 COMBO PRESS AND TEMP SNSR RTN N/A
96 K37 WH/RD 0.50 BOOST PRESSURE SIGNAL N/A
97 K922 WH/BK 0.50 TP SENSOR RETURN N/A
98 K22 YE/DB 0.50 TP 1 SIGNAL N/A
99 K200 GY/GN 0.50 COOLANT TEMPERATURE SENSOR RETURN 1.6L DIESEL
100 K2 DB/RD 0.50 ECT SIGNAL N/A
104 K89 RD/WH 0.50 O2 1/1 POSITIVE CURRENT CONTROL N/A
105 K103 BK/WH 0.50 O2 1/1 PUMP CELL CURRENT TRIM N/A
(1) Pins not listed are not used for this connector
