Module-Intrusion Transceiver C2 (D3851B)

Harness-Family: Headliner

Color: ~~

Gender: FEMALE

Part Number: 4707041

Part Description: Not Available

Connector No: D3851B

Option: Standard

Repair Kit Part Number: 68057308AA

Cavity Count: 3

Fig 1: Module-Intrusion Transceiver C2 Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Intrusion Transceiver C2 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z903

BK/WT

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
