Module-Fuel Pump (D6602)

Harness-Family: Body

Color: DARK GRAY

Gender: FEMALE

Part Number: 6189-0618

Part Description: 5P HXO90F/P (F) HOUSING ASSY

Connector No: D6602

Option: Standard

Repair Kit Part Number: 68020945AA

Cavity Count: 5

Fig 1: Module-Fuel Pump Connector End View

GCWD1024721

Courtesy of CHRYSLER

Fig 2: Module-Fuel Pump Component Location

GCWD1077693

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

Z906

BK/GY

20

GROUND

N/A

2

N4

DB/WT

22

FUEL LEVEL SENSOR SIGNAL

N/A

4

Z906

BK/WT

~~

GROUND

N/A

5

N1

DB/OR

16

FUEL PUMP CONTROL OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
