Module-Transmission Control C1 (CVT) (D3855A)

Harness-Family: Body

Color: ~~

Gender: FEMALE

Part Number: 7283-4781

Part Description: Not Available

Connector No: D3855A

Option: CVT

Repair Kit Part Number: 68020947AA

Cavity Count: 24

Fig 1: Module-Transmission Control C1 Connector End View (CVT)
GCWD1024406Courtesy of CHRYSLER
Fig 2: Module-Transmission Control C1 Component Location (CVT)
GCWD1055162Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
A1 T20 DG/LB 20 L/R CONTROL N/A
A10 T16 YL/OR 18 TRANSMISSION CONTROL OUTPUT N/A
A11 T314 LB/YL 20 STEP MOTOR CONTROL A N/A
A12 T315 YL/OR 20 STEP MOTOR CONTROL B N/A
A13 T302 DG/BR 20 CLOCK SELECT N/A
A14 T313 YL/LG 20 CHIP SELECT N/A
A15 T327 GY/YL 20 DATA IN/OUT SELECT N/A
A18 T41 YL/BK 20 TRS T41 SIGNAL N/A
A19 T16 YL/OR 18 TRANSMISSION CONTROL OUTPUT N/A
A2 T19 YL/DB 20 2-4 CONTROL N/A
A20 T316 YL/WT 20 STEP MOTOR CONTROL C N/A
A21 T317 TN/YL 20 STEP MOTOR CONTROL D N/A
A22 T42 DG/PK 20 TRS T42 SIGNAL N/A
A3 T59 YL/LB 20 UD CONTROL N/A
A4 T60 YL/GY 20 OD CONTROL N/A
A5 D65 WT/BK 22 CAN C (+) N/A
A6 D64 WT/LB 22 CAN C (-) N/A
(1) Pins not listed are not used for this connector
