Exhaust System: Description: Diesel

Fig 1: Exhaust System Components

Courtesy of CHRYSLER GROUP, LLC

The exhaust system on the 2.0L diesel engine models consists of a Turbocharger, Diesel Particulate Filter (DPF), front exhaust pipe, resonator, muffler assembly, band clamp, and support isolators. The upstream oxygen sensor is located in the Diesel Particulate Filter (DPF).
