Screen-Air Inlet
WARNING: This page is about a different car, the 2009 Jeep Liberty. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
LHD model shown in illustration. RHD model similar.
- Position the air inlet screen (1) into the cowl panel (3) and fully engage the screen onto the two retaining studs (4).
- Install the air inlet screen onto the cowl panel and install the two retaining nuts (4). Tighten the nuts to 2.3 N.m (20 in. lbs.).
- Install the cowl grille. Refer to Body/Exterior/COVER, Cowl Panel - Installation .
