Connector End Views & Electrical Component Locations: S389

Harness-Family: Body

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S126

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S389 Connector End View

Courtesy of CHRYSLER

Fig 2: S389 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

X209

GY/OR

AMPLIFIED LEFT I/P SPEAKER (+)

N/A

X209

GY/OR

AMPLIFIED LEFT I/P SPEAKER (+)

N/A

X209

GY/OR

AMPLIFIED LEFT I/P SPEAKER (+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
