Connector End Views & Electrical Component Locations: S383

Harness-Family: Body

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S135

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S383 Connector End View

Courtesy of CHRYSLER

Fig 2: S383 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

G78

VT/OR

DECKLID/LIFTGATE AJAR SWITCH SENSE

N/A

G78

VT/OR

DECKLID/LIFTGATE AJAR SWITCH SENSE

N/A

G78

VT/OR

DECKLID/LIFTGATE AJAR SWITCH SENSE

N/A

⁽¹⁾	Pins not listed are not used for this connector
