Connector End Views & Electrical Component Locations: S375

Harness-Family: Body

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S133

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S375 Connector End View

Courtesy of CHRYSLER

Fig 2: S375 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Q901

OR/VT

LOGIC GROUND

N/A

Q901

OR/VT

LOGIC GROUND

N/A

Q901

OR/VT

LOGIC GROUND

N/A

Q901

OR/VT

LOGIC GROUND

N/A

Q901

OR/VT

LOGIC GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
