Connector End Views & Electrical Component Locations: S160

Harness-Family: HDLP_Dash

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1343

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S160 Connector End View

Courtesy of CHRYSLER

Fig 2: S160 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L962

WT/BR

HEADLAMP LEVELING SENSOR RETURN

N/A

L962

WT/BR

HEADLAMP LEVELING SENSOR RETURN

N/A

L962

WT/BR

HEADLAMP LEVELING SENSOR RETURN

N/A

⁽¹⁾	Pins not listed are not used for this connector
