Connector End Views & Electrical Component Locations: S360

Harness-Family: Body_Under

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S328

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S360 Connector End View

Courtesy of CHRYSLER

Fig 2: S360 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T312

YL/VT

REAR DIFFERENTIAL SOLENOID CONTROL

N/A

T312

YL/VT

REAR DIFFERENTIAL SOLENOID CONTROL

N/A

⁽¹⁾	Pins not listed are not used for this connector
