Connector End Views & Electrical Component Locations: S338

Harness-Family: Body_Under

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S323

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S338 Connector End View

Courtesy of CHRYSLER

Fig 2: S338 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T315

YL/BR

SHIFT MOTOR CONTROL A

N/A

T315

YL/BR

SHIFT MOTOR CONTROL A

N/A

⁽¹⁾	Pins not listed are not used for this connector
