Connector End Views & Electrical Component Locations: S313

Harness-Family: Body

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S113

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S313 Connector End View

Courtesy of CHRYSLER

Fig 2: S313 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P778

LG/LB

DOOR LOCK RELAY OUTPUT

N/A

P778

LG/LB

DOOR LOCK RELAY OUTPUT

N/A

P778

LG/LB

DOOR LOCK RELAY OUTPUT

N/A

P778

LG/LB

DOOR LOCK RELAY OUTPUT

N/A

P778

LG/LB

DOOR LOCK RELAY OUTPUT

N/A

P778

LG/LB

DOOR LOCK RELAY OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
