Connector End Views & Electrical Component Locations: S308
Harness-Family: Body
Color: NA
Gender: FEMALE
Part Number: NA
Part Description: Not Available
Connector No: S108
Option: Standard
Repair Kit Part Number: Not Available
Cavity Count:
| Pin | Circuit | Wire Color | Gauge/Size | Function | Option | ||
|---|---|---|---|---|---|---|---|
| 1 | D54 | WT | 20 | CAN B (-) | N/A | ||
| 2 | D54 | WT | 20 | CAN B (-) | N/A | ||
| 3 | D54 | WT | 20 | CAN B (-) | N/A | ||
| 4 | D54 | WT | 20 | CAN B (-) | N/A | ||
| 5 | D54 | WT | 20 | CAN B (-) | N/A | ||
| 6 | D54 | WT | 20 | CAN B (-) | N/A | ||
| 7 | D54 | WT | 20 | CAN B (-) | N/A | ||
| 8 | D54 | WT | 20 | CAN B (-) | N/A | ||
| 9 | D54 | WT | 20 | CAN B (-) | N/A | ||
| 10 | D54 | WT | 20 | CAN B (-) | N/A | ||
|
|||||||
