Connector End Views & Electrical Component Locations: S252

Harness-Family: IP

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1650

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S252 Connector End View

Courtesy of CHRYSLER

Fig 2: S252 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

X543

DG/BR

VIDEO SHIELD 2

N/A

X543

DG/BR

VIDEO SHIELD 2

N/A

⁽¹⁾	Pins not listed are not used for this connector
