Connector End Views & Electrical Component Locations: S239
Harness-Family: Body
Color: NA
Gender: FEMALE
Part Number: NA
Part Description: Not Available
Connector No: S151
Option: Standard
Repair Kit Part Number: Not Available
Cavity Count:
| Pin | Circuit | Wire Color | Gauge/Size | Function | Option | ||
|---|---|---|---|---|---|---|---|
| 1 | P114 | TN/WT | 22 | AUTO DAY/NIGHT MIRROR (-) | N/A | ||
| 2 | P114 | TN/WT | 22 | AUTO DAY/NIGHT MIRROR (-) | N/A | ||
| 3 | P114 | TN/WT | 22 | AUTO DAY/NIGHT MIRROR (-) | N/A | ||
|
|||||||
