Connector End Views & Electrical Component Locations: S230

Harness-Family: IP

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1630

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S230 Connector End View

Courtesy of CHRYSLER

Fig 2: S230 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

OR/BR

PANEL LAMPS DRIVER

N/A

OR/BR

PANEL LAMPS DRIVER

N/A

OR/BR

PANEL LAMPS DRIVER

N/A

OR/BR

PANEL LAMPS DRIVER

N/A

OR/BR

PANEL LAMPS DRIVER

N/A

OR/BR

PANEL LAMPS DRIVER

N/A

OR/BR

PANEL LAMPS DRIVER

N/A

OR/BR

PANEL LAMPS DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
