Connector End Views & Electrical Component Locations: S218

Harness-Family: IP

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1642

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S218 Connector End View
GCWD1006457Courtesy of CHRYSLER
Fig 2: S218 Component Location
GCWD1225335Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 D500 WT 22 LIN BUS N/A
2 D500 WT 22 LIN BUS N/A
3 D500 WT 22 LIN BUS N/A
4 D500 WT 22 LIN BUS N/A
5 D500 WT 22 LIN BUS N/A
6 D500 WT 22 LIN BUS N/A
(1) Pins not listed are not used for this connector
