Connector End Views & Electrical Component Locations: S208

Harness-Family: IP

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S1608

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S208 Connector End View
GCWD1006457Courtesy of CHRYSLER
Fig 2: S208 Component Location
GCWD1225242Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 M22 YL/OR 20 COURTESY LAMPS DRIVER N/A
2 M22 YL/OR 20 COURTESY LAMPS DRIVER N/A
3 M22 YL/OR 20 COURTESY LAMPS DRIVER N/A
4 M22 YL/OR 20 COURTESY LAMPS DRIVER N/A
(1) Pins not listed are not used for this connector
