Connector End Views & Electrical Component Locations: S149

Harness-Family: Engine

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S960

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S149 Connector End View

Courtesy of CHRYSLER

Fig 2: S149 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

F42

DG/LG

FUSED ASD RELAY OUTPUT

N/A

F42

DG/LG

FUSED ASD RELAY OUTPUT

N/A

F42

DG/LG

FUSED ASD RELAY OUTPUT

N/A

F42

DG/LG

FUSED ASD RELAY OUTPUT

N/A

F42

DG/LG

FUSED ASD RELAY OUTPUT

N/A

F42

DG/LG

FUSED ASD RELAY OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
