Connector End Views & Electrical Component Locations: S142

Harness-Family: Engine

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S912

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S142 Connector End View

Courtesy of CHRYSLER

Fig 2: S142 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K902

BR/DG

O2 RETURN (UPSTREAM)

N/A

K902

BR/DG

O2 RETURN (UPSTREAM)

N/A

K902

BR/DG

O2 RETURN (UPSTREAM)

N/A

⁽¹⁾	Pins not listed are not used for this connector
