Connector End Views & Electrical Component Locations: S140

Harness-Family: Engine

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S907

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S140 Connector End View
GCWD1006457Courtesy of CHRYSLER
Fig 2: S140 Component Location
GCWD1225375Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 F856 YL/PK 20 5 VOLT SUPPLY N/A
2 F856 YL/PK 20 5 VOLT SUPPLY N/A
3 F856 YL/PK 20 5 VOLT SUPPLY N/A
4 F856 YL/PK 20 5 VOLT SUPPLY N/A
5 F856 YL/PK 20 5 VOLT SUPPLY N/A
(1) Pins not listed are not used for this connector
