Front Washer Nozzle
Courtesy of CHRYSLER LLC
- From the underside of the hood, remove the push-in retainers that secure the hood silencer pad to the inner hood reinforcement (4) as necessary to access the front washer nozzle (2 or 3) hose connections.
- Disconnect the hose (1) from the barbed nipple of the front washer nozzle.
Courtesy of CHRYSLER LLC
- From the underside of the hood, release the integral latches of the front washer nozzle (1 or 2) and push the nozzle out through the mounting hole toward the top side of the hood (3).
- Remove the nozzle from the top of the hood panel.
