Wiring Trailer Tow Terminal Connector End View

WARNING: This page is about a different car, the 2008 Jeep Grand Cherokee, 2007 Jeep Grand Cherokee, and 2006 Jeep Grand Cherokee. However, it is still accessible from the selected car via links, so may be relevant.
WIRING-TRAILER TOW TERMINAL - 1 WAY

GCWH680461Courtesy of DAIMLERCHRYSLER CORP.
CAV CIRCUIT FUNCTION
1 B400 14DG TRAILER TOW ELECTRIC BRAKE OUTPUT
