Compass Mini/Trip Computer: Removal

  1. Remove overhead console, refer to REMOVAL  .
  2. Remove mounting screws and release the map lamp wire connector from the compass mini-trip computer. (Fig 1 ).
    Fig 1: Locating Compass Mini-Trip Computer Retaining Screws
    G02706258Courtesy of DAIMLERCHRYSLER CORP.
  3. Remove the compass mini-trip computer from the overhead console.
