Front Servo: Description
The kickdown servo consists of a two-land piston with an inner piston, a piston rod and guide, and a return spring. The dual-land piston uses seal rings on its outer diameters and an O-ring for the inner piston.
Courtesy of DAIMLERCHRYSLER CORP.
