Fault 1066: Rich O2 Sensor Input

NOTE: For additional oxygen sensor information, see TITANIA OXYGEN SENSOR TESTING article.

Fig 1: Fault 1066: Circuit Diagram Rich O2 Sensor Input

Fig 2: Fault 1066: Flow Chart Rich O2 Sensor Input
