Code 818 - Left Front Wheel Speed Sensor Fault

Fig 1: ABS Module Connector
G93A45559
Fig 2: Speed Sensor Connector (Harness Side)
G93E45561
Fig 3: Fault 818: Left Front Wheel Speed Sensor Fault
G50F00401
Fig 4: Fault 818: Left Front Wheel Speed Sensor Fault
GB0010728
