Control Panel: Notes

On CJ and Scrambler, heater and defroster controls consist of a fan control switch and 3 push-pull knobs on instrument panel.

Fig 1: Heater Control Panel (CJ and Scrambler) Push-pull knobs are cable operated.
G17578
