Instrument Panel Register Trim Panel: Installation

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2012 Jaguar XFR, 2012 Jaguar XF, 2011 Jaguar XFR, 2011 Jaguar XF, and 2010 Jaguar XFR. However, it is still accessible from the selected car via links, so may be relevant.

CAUTION: Make sure that the clutch rib is located between the two ribs on the car rearward (front half), of the register housing to avoid damage on installation.

To install, reverse the removal procedure.
- Position the locating peg.
