Front Bumper: Installation
To install, follow the removal steps in reverse order noting the following points:
- Tighten the front bumper assembly fixing bolts to the specified torque. Torque: 147 N.m (108 lb ft)
- Front bumper adjustment
- When the bolts fixing front bumper assembly are tightened, adjustment should be made between the backbar and front side bumper so that a clearance of 14.5 mm (0.57 in) is provided between the lower side of the fender and the upper side of the front bumper.
