Rear Door Lock Assembly: Installation

To install, follow the removal steps in the reverse order, noting the following points.

1. Apply chassis grease to the lock assembly and striker moving surface.
2. Install the regulator handle as shown in the illustration, if equipped without power windows.
   Fig 1: Identifying Regulator Handle

   Courtesy of ISUZU MOTOR CO.
3. Tighten the door lock assembly fixing screws to the specified torque. Torque:  7 N.m (61 lb in)
4. Check that the door lock operates smoothly.
