Front Door Lock Assembly: Installation

To install, follow the removal steps in the reverse order, noting the following points:

1. Apply chassis grease to the lock assembly and striker moving surface.
2. Install the regulator handle as shown in the illustration, if equipped without power windows.
   Fig 1: Identifying Regulator Handle

   Courtesy of ISUZU MOTOR CO.
3. Tighten the door lock assembly fixing screws to the specified torque. Torque:  7 N.m (61 lb in)
4. Check that the door lock operates smoothly.
