Home >> Isuzu >> 2004 >> Axiom Base, 4WD >> Repair and Diagnosis >> Steering >> Power Steering >> Power-Assisted Steering System >> Front End Alignment Inspection and Adjustment >> Main Data and Specifications >> Torque Specification

Torque Specification

Fig 1: Front End Alignment Torque Specification
G02714360Courtesy of ISUZU MOTOR CO.
